Frame
City 20" x 320mm Folding Alloy 6061 135mm QR Integrated battery
Seat Post
SIGNUM Alloy Silver 30,4x500mm
Stem
SIGNUM Alloy foldable
Shift Lever
SHIMANO TOURNEY SL-RS36 6 speed
Cassette
SHIMANO TZ500 14-28 7 speed
Tyres
SCHALWBE Big Apple 20×2.15
Kickstand
URSUS Alloy
saddle
SIGNUM City Line
Display
KD58C led full function set
Fork
SIGNUM EC106D travel 25mm
Handlebar
SIGNUM Folding 580mm w/HERRMANS Moza
Rear Derailleur
SHIMANO Tourney RD-TY300 6 speed
Crankset
SIGNUM Steel 44 x 170mm
Wheels
F: SIGNUM Alloy 36h 20" – Alloy hub, R: SIGNUM Alloy 36h 20" – BAFANG G010 Hub motor 36V 250W
Brakes
SHIMANO MT200 or TEKTRO T275 Hydraulic Disc Brake Rotor 160 -160
Lights
F : SPANNINGA Kendo 40 controlled by display R : SPANNINGA Pimento large controlled by display
Drive Unit
BAFANG G010 Rear Hub Motor 36v 250w 35Nm Torque
Battery
SIGNUM 36v 14ah 504Wh
GEOMETRIE
| SIZE | A | B | C | D | E | F | G | H | I |
|---|---|---|---|---|---|---|---|---|---|
| 31cm | 310 | 615 | 641 | 160 | 71° | 680 | 1110 | 430 | 73° |
